Usage

Lightbox opens media in a native <dialog>. Bind isOpen with v-model:is-open. A single media object is one image or video. An array is a gallery: previous, next, and a counter stay mounted, and the ends disable instead of disappearing.

useLightbox({ media }) owns the open state and the index. Bind bindings onto Lightbox, and call open(index) from a thumbnail.

hasZoom turns an image into a button. Double-click, Enter, Space, +, and - toggle between 1× and 2×. While zoomed, drag or the arrow keys pan; each arrow moves 50px. A drag does not also close the dialog. Video items keep the browser controls and do not zoom. hasAutoPlay starts a video when that item is shown.

Escape and the close button emit update:isOpen with false. A backdrop click on the dialog or the frame does the same.

vue

<script setup lang="ts">
import { Lightbox, useLightbox } from '@astryx-vue/core/Lightbox'
import { Thumbnail } from '@astryx-vue/core/Thumbnail'

const photo = {
  src: '/template-assets/light-scene-horizontal-1.png',
  alt: 'Coastal shoreline with ocean waves',
  caption: 'A scenic coastline with waves rolling onto a sandy beach beneath a clear sky.',
}
const { bindings, open } = useLightbox({ media: photo })
</script>

<template>
  <Thumbnail :src="photo.src" :alt="photo.alt" :label="photo.alt" @click="open()" />
  <Lightbox v-bind="bindings" />
</template>

Anatomy

Element	Description
Viewer overlay	Full-viewport dialog overlay that contains the active media and controls.
Media	Active image or video presented inside the viewer.
Close button	Button that closes the viewer.
Previous button	Gallery button that moves to the previous media item.
Next button	Gallery button that moves to the next media item.
Caption	Caller-provided caption displayed below the active media.
Counter	Current position and total shown in gallery mode.

Best practices

Guidance	Practices
Do	Write an `alt` that names the picture, and a `caption` that adds what the picture itself does not say.
Do	Open a gallery at the thumbnail the reader chose, with `open(index)`.
Do	Turn on `hasZoom` only for a still image that has detail worth inspecting.
Don't	Put `hasZoom` on a video. The controls stay native, and zoom is ignored.
Don't	Leave `alt` empty. The dialog name and the image name both come from it.

Examples

Gallery

A thumbnail grid that opens a fullscreen gallery. Clicking any thumbnail opens the lightbox at that index. Previous and next browse the rest without closing.

Video

Opens a video with the browser controls. Zoom and pan stay off for video.

Zoom

Double-click the image to zoom in, then drag to pan. Double-click again, or close, to leave zoom.
